- Honda Mini 4-Stroke Engine
- Pumps up to 72 Gallons/Minute
- Fuel Efficient
- Easy Starting
- Strainer
- Hose Clamps
- 2 Year Residential Warranty
- 2 Year Commercial Warranty
| Model Number |
WX15T |
| Engine |
GXH50 |
| Displacement |
49 cc |
| Bore and Stroke |
1.65" x 1.42" |
| Compression Ratio |
8.0:1 |
| Oil Alert |
Standard |
| Pump Type |
General Purpose, Centrifugal, Self-Priming |
| Volute |
Aluminum |
| Impeller |
Aluminum |
| Mechanical Seal (Pump case / impeller) |
Carbon/Ceramic |
| Priming Time |
120 sec. at 16.4 ft. |
| Drive System |
Direct |
| Discharge Capacity |
74 gals./min. |
| Suction Port Diameter |
1.5" NPT |
| Discharge Port Diameter |
1.5" NPT |
| Total Head Lift |
121 ft. |
| Suction Head Lift |
26 ft. |
| Maximum Pressure |
54 psi |
| Solids Handling |
N/A |
| Dimensions |
14.0" x 10.8" x 14.8" |
| Dry Weight |
20.0 lbs |
| Fuel Capacity |
0.20 gal |
| Run Time @ Max Discharge |
0.9 hr |
| Strainer Part # |
78325-YB0-751 |
| Residential Warranty |
2 years |
| Commerical Warranty |
1 year |
|
